Astrotek 2m Micro USB Charger Cable

High-Performance Quad-Core Short Depth TS-431XeU

The high-performance quad-core short depth TS-431XeU includes a 10GbE SFP+ port to fully support 10GbE high-speed networks at a budget price with maximized ROI. The short depth design is perfectly suitable for installing the TS-431XeU in a compact rack, or places with a lot of cabling. The TS-431XeU provides versatile all-in-one functionality and unique features including VJBOD (Virtual JBOD) - an economical way to utilize unused NAS storage space for expanding the storage capacity of other QNAP NAS - and Container Station - that allows users to rapidly develop and deploy Internet of Things (IoT) apps. The TS-431XeU is a cost-effective storage solution designed for growing businesses looking for backup, restoration, private cloud, storage for virtualization, and to future-proof their IT infrastructure for 10GbE networks.

Specifications

• CPU: AnnapurnaLabs Alpine AL314 32-bit ARM® Cortex-A15 quad-core 1.7GHz processor
• CPU Architecture: 32-bit ARM
• Floating Point Unit
• Encryption Engine
• System Memory: 2 GB SODIMM DDR3 (1 x 2 GB)
• Maximum Memory: 8 GB (1 x 8 GB)
• Memory Slot: 1 x SO-DIMM DDR3
• Flash Memory: 512MB (Dual boot OS protection)
• Drive Bay: 4 x 3.5-inch SATA 6Gb/s, 3Gb/s
• Hot-swappable
• SSD Cache Acceleration Support
• Gigabit Ethernet Port (RJ45): 2
• 10 Gigabit Ethernet Port: 1 x 10GbE SFP+
• Jumbo Frame
• USB 3.2 Gen 1 port: 4
• Form Factor: 1U Rackmount
• LED Indicators: HDD 1-4, Status, USB, LAN1-3
• Dimensions (HxWxD): 44 × 439 × 291 mm
• Weight (Net): 4.15 kg
• Operating temperature: 0 - 40 °C (32°F - 104°F)
• Power Consumption: HDD Sleep Mode: 12.42 W
• Fan: System fan: 3 x 40mm, 12VDC
